USMA Bearing 22320 E EK/C3 Bearing Rollers 22320 MB 22320-E1-XL-T41D Spherical Bearings 22322 22222 22220 21320
Bearing 22320 E EK/C3 Spherical Roller Bearing 22320 MB 22320-E1-XL-T41D Spherical Bearings 22322 22222 22220 21320
| Quantity: | |
|---|---|
-
22320
-
USMA
USMA Bearing 22320 E EK/C3 Bearing Rollers 22320 MB 22320-E1-XL-T41D Spherical Bearings 22322 22222 22220 21320
Spherical roller bearings have two types of inner holes: cylindrical and conical, and the taper of the conical taper hole is 1:30 and 1:12. This conical inner hole bearing is equipped with an adapter sleeve or a withdrawal sleeve. The tapered inner hole self-aligning ball bearing can be easily and quickly assembled on the smooth shaft or stepped machine shaft
Spherical roller bearings have high load ratings and self-aligning features, making them suitable for low/medium speed applications where heavy loads and shocks are present. The housing raceway surface of this bearing is spherical, so it can self-align and correct shaft tilting problems.
| Series | Model Number | d(mm) | D(mm) | B(mm) | Series | Model Number | d(mm) | D(mm) | B(mm) |
| 21300 series | 21307 | 35 | 72 | 23 | 22200 series | 22205 | 25 | 52 | 18 |
| 21308 | 40 | 90 | 23 | 22206 | 30 | 62 | 20 | ||
| 21309 | 45 | 100 | 25 | 22207 | 35 | 72 | 23 | ||
| 21310 | 50 | 110 | 27 | 22208 | 40 | 80 | 23 | ||
| 21311 | 55 | 120 | 29 | 22209 | 45 | 85 | 23 | ||
| ... | ... | ... | .. | ... |
As a wholesaler, we are committed to providing you with high-end durable bearings. At the same time, as an distributor, we can provide you with a more favorable price than the market price.
USMA Bearing 22320 E EK/C3 Bearing Rollers 22320 MB 22320-E1-XL-T41D Spherical Bearings 22322 22222 22220 21320
Spherical roller bearings have two types of inner holes: cylindrical and conical, and the taper of the conical taper hole is 1:30 and 1:12. This conical inner hole bearing is equipped with an adapter sleeve or a withdrawal sleeve. The tapered inner hole self-aligning ball bearing can be easily and quickly assembled on the smooth shaft or stepped machine shaft
Spherical roller bearings have high load ratings and self-aligning features, making them suitable for low/medium speed applications where heavy loads and shocks are present. The housing raceway surface of this bearing is spherical, so it can self-align and correct shaft tilting problems.
| Series | Model Number | d(mm) | D(mm) | B(mm) | Series | Model Number | d(mm) | D(mm) | B(mm) |
| 21300 series | 21307 | 35 | 72 | 23 | 22200 series | 22205 | 25 | 52 | 18 |
| 21308 | 40 | 90 | 23 | 22206 | 30 | 62 | 20 | ||
| 21309 | 45 | 100 | 25 | 22207 | 35 | 72 | 23 | ||
| 21310 | 50 | 110 | 27 | 22208 | 40 | 80 | 23 | ||
| 21311 | 55 | 120 | 29 | 22209 | 45 | 85 | 23 | ||
| ... | ... | ... | .. | ... |
As a wholesaler, we are committed to providing you with high-end durable bearings. At the same time, as an distributor, we can provide you with a more favorable price than the market price.
